• Product colour: Black
• Mounting type: Ceiling/wall
• Protection features: Water resistant, Dust resistant, Vandal proof
• Form factor: Dome
• International Protection (IP) code: IP67
• Housing material: Aluminium
• IK code: IK10

• Power source type: DC, PoE
• DC output current: 0.65 A
• DC output voltage: 12
• Power consumption (max): 7.8 W
• Power consumption (Power over Ethernet (PoE)): 9.5 W

• Pixel counter: Yes
• Alarm output channels: 1
• Security algorithms: TLS
• Alarm input channels: 1
• Active tampering alarm: Yes
• Password reset via email: Yes
• Mirror: Yes
• Video motion detection: Yes
• IP address filtering: Yes
• Heartbeat: Yes
• HTTPS encryption: Yes
• Digest authentication: Yes
• Audit log: Yes
• Password protection: Yes
• Automatic Network Replenishment (ANR): Yes

• Operating temperature (T-T): -30 - 60 °C
• Storage temperature (T-T): -30 - 60 °C
• Storage relative humidity (H-H): 0 - 95%
• Operating relative humidity (H-H): 0 - 95%

• Reset button: Yes
• Behavior analysis: Line crossing detection
• Web browser: Yes

• Height: 97.6 mm
• Weight: 600 g
• Diameter: 12.2 cm

• Number of simultaneous live view channels: 6 channels
• Ethernet interface type: Fast Ethernet
• Ethernet LAN: Yes
• Bluetooth: No
• Networking standards: IEEE 802.3af
• Number of users: 32 user(s)
• User access level: Administrator, Operator, User
• Wi-Fi: No
• Live view: Yes

• Day/night mode: Yes
• Placement supported: Indoor & outdoor
• Infrared (IR) cut-off filter: Yes
• Dynamic range: 120 dB
• Connectivity technology: Wired
• Number of languages: 33
• Alarm input/output: Yes
• Type: IP security camera
• Wide Dynamic Range (WDR): Yes
• Languages support: Multi

• Package height: 141 mm
• Package width: 150 mm
• Package weight: 840 g
• Package depth: 150 mm

• Signal-to-Noise Ratio (SNR): 52 dB
• Bit rate range: 8 - 320 Kbit/s
• Sample rates: 8 - 48 kHz
• Built-in microphone: Yes
• Audio output channels: 1.0 channels
• Audio input channels: 1.0 channels
• Audio codecs: G. 711/G. 722.1/G. 726/MP2L2/PCM/MP3/AAC-LC
• Number of microphones: 2

• Compatible memory cards: MicroSD (TransFlash), MicroSDXC, MicroSDHC
• Maximum memory card size: 512 GB
• Built-in HDD: No
• Card reader integrated: Yes

• Ethernet LAN (RJ-45) ports: 1
• Terminal block port: Yes

• Minimum illumination: 0 lx
• Lens viewing angle, horizontal: 108°
• Pan range: 0 - 355°
• Lens viewing angle, vertical: 59°
• Lens viewing angle, diagonal: 127°
• Tilt angle range: 0 - 75°
• Camera shutter speed: 1/3 - 1/100000 s
• Number of Privacy masking areas: 8
• Angle of rotation: 355°

• Number of sensors: 1
• Progressive scan: Yes
• Sensor type: CMOS
• Optical sensor size: 25.4 / 2.8 mm (1 / 2.8")

• Noise reduction: Yes
• Supported graphics resolutions: 1920 x 1080 (HD 1080), 640 x 360, 2688 x 1520, 1280 x 720 (HD 720), 3200 x 1800, 640 x 480 (VGA), 3840 x 2160
• Video streaming: Yes
• Total megapixels: 8 MP
• Gain control type: Auto
• Noise reduction technology: 3D noise reduction
• Video compression formats: H. 264+, H. 265+, H. 265, H. 264
• Bit rate: 32 Kbps - 16 Mbps
• Maximum resolution: 3840 x 2160 pixels
• Back Light Compensation (BLC): Yes
• Highlight Compensation (HLC): Yes
• Region of Interest (ROI) encoding: Yes
• Bit rate control: Constant Bit Rate (CBR)/Variable Bit Rate (VBR)
• Frame rate: 30 fps
• Video recording: Yes

• Night vision: Yes
• LED type: IR/White
• Night vision distance: 30 m
• Infra-red wavelength: 850 nm

• Recognize distance: 16 m
• Identify distance: 8 m
• Maximum aperture number: 1.6
• Fixed focal length: 2.8 mm
• Number of lenses: 1
• Observe distance: 33 m
• Detect distance: 84 m
