Termékleírás
| Kialakítás | Turret kamera |
| Energiaforrás | Hálózat és PoE |
| Felbontás | 4 MPx |
| Minimális fókusztávolság | 2.7 mm |
| Maximális fókusztávolság | 13.5 mm |
| IP védettség | IP67 |
| Éjjellátó funkció | Van |
Hibát talált a leírásban vagy az adatlapon? Jelezze nekünk!
Camera
Image Sensor
1/3 4Megapixel progressive CMOS
Max. Resolution
2688 (H) × 1520 (V)
ROM
128 MB
RAM
128 MB
Scanning System
Progressive
Electronic Shutter Speed
Auto/Manual 1/3 s–1/100000 s
Min. Illumination
0.008 Lux@F1.5
S/N Ratio
>56 dB
Illumination Distance
40 m (131.23 ft)
Illuminator On/Off Control
Auto/Manual
Illuminator Number
2 (IR LED)
Pan/Tilt/Rotation Range
Pan 0°–360°
Tilt: 0°–78°
Rotation: 0°–360°
Lens
Lens Type
Motorized vari-focal
Mount Type
φ14
Focal Length
2.7 mm–13.5 mm
Max. Aperture
F1.5
Field of View
Horizontal: 104°–27°
Vertical: 55°–15°
Diagonal: 124°–31°
Iris Type
Fixed
Close Focus Distance
0.8 m–0.8 m (2.62 ft–2.62 ft)
DORI Distance
Lens
Detect
Observe
Recognize
Identify
W
64 m
(209.97 ft)
25.6 m
(83.99 ft)
12.8 m
(41.99 ft)
6.4 m
(21.00 ft)
T
220 m
(721.78 ft)
88 m
(288.71 ft)
44 m
(144.36 ft)
22 m
(72.18 ft)
Smart Event
IVS
Tripwire; intrusion
Video
Video Compression
H. 265; H. 264; H. 264B; MJPEG (only supported by the sub stream)
Smart Codec
Smart H. 265+/ Smart H. 264+
Video Frame Rate
Main stream:
2688 × 1520 (1 fps-20 fps)
2560 × 1440 (1 fps-25/30 fps)
Sub stream:
704 × 576 (1 fps-25 fps)
704 × 480 (1 fps-30 fps)
Stream Capability
2 streams
Resolution
2688 × 1520 (2688 × 1520); 2560 × 1440 (2560 × 1440); 2304 × 1296 (2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 ×480); CIF (352 × 288/352 × 240)
Bit Rate Control
CBR/VBR
Video Bit Rate
H. 264: 32 kbps–6144 kbps
H. 265: 12 kbps–6144 kbps
Day/Night
Auto(ICR)/Color/B/W
BLC
Yes
HLC
Yes
WDR
120 dB
White Balance
Auto/natural/street lamp/outdoor/manual/regional custom
Gain Control
Auto/Manual
Noise Reduction
3D NR
Motion Detection
OFF/ON (4 areas, rectangular)
Region of Interest(RoI)
Yes (4 areas)
Smart Illumination
Yes
Image Rotation
0°/90°/180°/270° (Supports 90°/270° with 2688 × 1520 resolution and lower. )
Mirror
Yes
Privacy Masking
4 areas
Alarm
Alarm Event
No SD card; SD card full; SD card error; network disconnection; IP conflict; motion detection; video tampering; tripwire; intrusion; illegal access; voltage detection; safety exception;
Network
Network
RJ-45 (10/100 Base-T)
SDK and API
Yes
Cyber Security
Video encryption; firmware encryption; configuration encryption; Digest; WSSE; account lockout; security logs; IP/MAC filtering; generation and importing of X. 509 certification; syslog; HTTPS; 802.1x; trusted boot; trusted execution; trusted upgrade
Protocol
IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP ; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; PPPoE; Bonjour
Interoperability
ONVIF (Profile S/Profile G/Profile T); CGI; P2P; Milestone; Genetec
User/Host
20
Storage
FTP; Micro SD card (support max. 256 G); NAS; SFTP
Browser
IE
Chrome
Firefox
Management Software
Smart PSS; DSS; DMSS
Mobile Phone
IOS; Android
Certification
Certifications
CE-LVD: EN62368-1
CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU
FCC: 47 CFR FCC Part 15, Subpart B
UL/CUL: UL60950-1 CAN/CSA C22.2 No. 60950-1-07
Power
Power Supply
12V DC/PoE (802.3af)
Power Consumption
< 6.4W
Environment
Operating Conditions
-30°C to +60°C (-22°F to +140°F)/less than ≤ 95% RH
Storage Temperature
-40°C to +60°C (-40°F to +140°F)
Protection
IP67
Structure
Casing
Metal
Dimensions
108.3 mm × Φ122 mm (4.26"" × Φ1.80"")
Net Weight
0.69 kg (1.52 lb)
Gross Weight
0.88 kg (1.94 lb)
Így is ismerheti: IPC HDW 2431 T ZS 27135 S 2, IPCHDW2431TZS27135S2, IPC HDW2431T ZS 27135 S2, IPC HDW2431T-ZS-27135-S2, IPC-HDW2431T-ZS 27135-S2
![]()
