Dahua IPC-HDW1830T-0280B-S6
Dahua IPC-HDW1830T-0280B-S6
59 999 Ft
Ajánlataink Dahua IPC-HDW1830T-0280B-S6 termékre
Ajánlataink a termékre
Paraméterek, termékleírás - Dahua IPC-HDW1830T-0280B-S6
Galéria - Dahua IPC-HDW1830T-0280B-S6
Árdiagram
Áttekintést kaphat a termék árának alakulásáról.
Árfigyelő
Árfigyelő szolgáltatásunk értesíti, ha a termék a megjelölt összeg alá esik.
Aktuális legalacsonyabb ár: 59 999 Ft
További termékek a kategóriából
További Dahua termékek: Dahua IP kamera
Termékleírás
| Kialakítás | Turret kamera |
| Felbontás | 8 MPx |
| IP védettség | IP67 |
| Éjjellátó funkció | Van |
Hibát talált a leírásban vagy az adatlapon? Jelezze nekünk!
Camera
Image Sensor
1/2.7"" CMOS
Max. Resolution
3840 (H) × 2160 (V)
ROM
16 MB
RAM
256 MB
Scanning System
Progressive
Electronic Shutter Speed
Auto/Manual 1/3 s–1/100,000 s
Min. Illumination
0.04 Lux@F2.0 (Color, 30 IRE)
0.004 Lux@F2.0 (B/W, 30 IRE)
0 Lux (Illuminator on)
S/N Ratio
> 56 dB
Illumination Distance
30 m (98.43 ft) (IR)
Illuminator On/Off Control
Auto/Manual
Illuminator Number
1 (IR LED)
Pan/Tilt/Rotation Range
Pan: 0°–360°
Tilt: 0°–90°
Rotation: 0°–360°
Lens
Lens Type
Fixed-focal
Lens Mount
M12
Focal Length
2.8 mm; 3.6 mm
Max. Aperture
2.8 mm: F2.0
3.6 mm: F2.0
Field of View
2.8 mm: Horizontal: 105°; Vertical: 56°; Diagonal: 125°
3.6 mm: Horizontal: 87°; Vertical: 47°; Diagonal: 104°
Iris Control
Fixed
Close Focus Distance
2.8 mm: 1.0 m (3.28 ft)
3.6 mm: 1.9 m (6.23 ft)
DORI Distance
Lens
Detect
Observe
Recognize
Identify
2.8 mm
74.7 m (245.08 ft)
29.9 m
(98.10 ft)
14.9 m
(48.88 ft)
7.5 m
(24.61 ft)
3.6 mm
106.7 m (350.07 ft)
42.7 m (140.09 ft)
21.3 m
(69.88 ft)
10.7 m
(35.10 ft)
Video
Video Compression
H. 265; H. 264; H. 264B; MJPEG (only supported by the sub stream)
Smart Codec
Smart H. 265+; Smart H. 264+
Video Frame Rate
Main stream:
3840 × 2160 (1 fps–15 fps)
2688 × 1520 (1 fps–25/30 fps)
Sub stream:
704 × 576 (1 fps–25 fps)
704 × 480 (1 fps–30 fps)
*The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity.
Stream Capability
2 streams
Resolution
3840 × 2160 (3840 × 2160); 3072 × 2048 (3072 × 2048); 3072 ×1728 (3072 × 1728); 2592 × 1944 (2592 × 1944); 2688 × 1520 (2688 × 1520); 3M (2048 × 1536); 2304 × 1296 (2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240)
Bit Rate Control
CBR/VBR
Video Bit Rate
H. 264: 32 kbps–8192 kbps
H. 265: 12 kbps–8192 kbps
Day/Night
Auto(ICR)/Color/B/W
BLC
Yes
HLC
Yes
WDR
DWDR
White Balance
Auto; natural; street lamp; outdoor; manual; regional custom
Gain Control
Auto; manual
Noise Reduction
3D NR
Motion Detection
OFF/ON (4 areas, rectangular)
Region of Interest (RoI)
Yes (4 areas)
Smart Illumination
Yes
Image Rotation
0°/90°/180°/270° (Support 90°/270° with 2688 × 1520 resolution and lower)
Mirror
Yes
Privacy Masking
4 areas
Audio
Built-in MIC
Yes
Audio Compression
G. 711a; G. 711Mu; G. 726; PCM
Alarm
Alarm Event
Network disconnection; IP conflict; illegal access; motion detection; video tampering; audio detection; security exception
Network
Network Port
RJ-45 (10/100 Base-T)
SDK and API
Yes
Cyber Security
Video encryption; configuration encryption; Digest; WSSE; account lockout; security logs; generation and importing of X. 509 certification; HTTPS; trusted boot; trusted execution; trusted upgrade
Network Protocol
IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; SMTP; FTP; DHCP; DNS; DDNS; NTP; Multicast
Interoperability
ONVIF (Profile S/Profile T); CGI; P2P; Genetec; Milestone
User/Host
6 (Total bandwidth: 48 M)
Storage
FTP
Browser
IE
Chrome
Firefox
Management Software
Smart PSS; DSS; DMSS
Mobile Client
IOS; Android
Certification
Certifications
CE-LVD: EN62368-1
CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU
FCC: 47 CFR FCC Part 15, Subpart B
Power
Power Supply
12V DC/PoE (802.3af)
Power Consumption
Basic: 2.4W (12V DC); 2.9W (PoE)
Max. (ICR + H. 265 + max. resolution + main stream + DWDR + IR intensity): 4.4W (12V DC); 5.2W (PoE)
Environment
Operating Temperature
–40°C to +60°C (–40°F to +140°F)
Operating Humidity
≤95%
Storage Temperature
–40°C to +60°C (–40°F to +140°F)
Protection
IP67
Structure
Casing
Metal
Product Dimensions
162.1 mm × Φ70.1 mm (6.38"" × Φ2.76"")
Net Weight
0.32 kg (0.71 lb)
Gross Weight
0.45 kg (0.99 lb)
Így is ismerheti: IPC HDW 1830 T 0280 B S 6, IPCHDW1830T0280BS6, IPC HDW1830T 0280B S6, IPC HDW1830T-0280B-S6, IPC-HDW1830T-0280B-S 6
![]()
Image Sensor
1/2.7"" CMOS
Max. Resolution
3840 (H) × 2160 (V)
ROM
16 MB
RAM
256 MB
Scanning System
Progressive
Electronic Shutter Speed
Auto/Manual 1/3 s–1/100,000 s
Min. Illumination
0.04 Lux@F2.0 (Color, 30 IRE)
0.004 Lux@F2.0 (B/W, 30 IRE)
0 Lux (Illuminator on)
S/N Ratio
> 56 dB
Illumination Distance
30 m (98.43 ft) (IR)
Illuminator On/Off Control
Auto/Manual
Illuminator Number
1 (IR LED)
Pan/Tilt/Rotation Range
Pan: 0°–360°
Tilt: 0°–90°
Rotation: 0°–360°
Lens
Lens Type
Fixed-focal
Lens Mount
M12
Focal Length
2.8 mm; 3.6 mm
Max. Aperture
2.8 mm: F2.0
3.6 mm: F2.0
Field of View
2.8 mm: Horizontal: 105°; Vertical: 56°; Diagonal: 125°
3.6 mm: Horizontal: 87°; Vertical: 47°; Diagonal: 104°
Iris Control
Fixed
Close Focus Distance
2.8 mm: 1.0 m (3.28 ft)
3.6 mm: 1.9 m (6.23 ft)
DORI Distance
Lens
Detect
Observe
Recognize
Identify
2.8 mm
74.7 m (245.08 ft)
29.9 m
(98.10 ft)
14.9 m
(48.88 ft)
7.5 m
(24.61 ft)
3.6 mm
106.7 m (350.07 ft)
42.7 m (140.09 ft)
21.3 m
(69.88 ft)
10.7 m
(35.10 ft)
Video
Video Compression
H. 265; H. 264; H. 264B; MJPEG (only supported by the sub stream)
Smart Codec
Smart H. 265+; Smart H. 264+
Video Frame Rate
Main stream:
3840 × 2160 (1 fps–15 fps)
2688 × 1520 (1 fps–25/30 fps)
Sub stream:
704 × 576 (1 fps–25 fps)
704 × 480 (1 fps–30 fps)
*The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity.
Stream Capability
2 streams
Resolution
3840 × 2160 (3840 × 2160); 3072 × 2048 (3072 × 2048); 3072 ×1728 (3072 × 1728); 2592 × 1944 (2592 × 1944); 2688 × 1520 (2688 × 1520); 3M (2048 × 1536); 2304 × 1296 (2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240)
Bit Rate Control
CBR/VBR
Video Bit Rate
H. 264: 32 kbps–8192 kbps
H. 265: 12 kbps–8192 kbps
Day/Night
Auto(ICR)/Color/B/W
BLC
Yes
HLC
Yes
WDR
DWDR
White Balance
Auto; natural; street lamp; outdoor; manual; regional custom
Gain Control
Auto; manual
Noise Reduction
3D NR
Motion Detection
OFF/ON (4 areas, rectangular)
Region of Interest (RoI)
Yes (4 areas)
Smart Illumination
Yes
Image Rotation
0°/90°/180°/270° (Support 90°/270° with 2688 × 1520 resolution and lower)
Mirror
Yes
Privacy Masking
4 areas
Audio
Built-in MIC
Yes
Audio Compression
G. 711a; G. 711Mu; G. 726; PCM
Alarm
Alarm Event
Network disconnection; IP conflict; illegal access; motion detection; video tampering; audio detection; security exception
Network
Network Port
RJ-45 (10/100 Base-T)
SDK and API
Yes
Cyber Security
Video encryption; configuration encryption; Digest; WSSE; account lockout; security logs; generation and importing of X. 509 certification; HTTPS; trusted boot; trusted execution; trusted upgrade
Network Protocol
IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; SMTP; FTP; DHCP; DNS; DDNS; NTP; Multicast
Interoperability
ONVIF (Profile S/Profile T); CGI; P2P; Genetec; Milestone
User/Host
6 (Total bandwidth: 48 M)
Storage
FTP
Browser
IE
Chrome
Firefox
Management Software
Smart PSS; DSS; DMSS
Mobile Client
IOS; Android
Certification
Certifications
CE-LVD: EN62368-1
CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU
FCC: 47 CFR FCC Part 15, Subpart B
Power
Power Supply
12V DC/PoE (802.3af)
Power Consumption
Basic: 2.4W (12V DC); 2.9W (PoE)
Max. (ICR + H. 265 + max. resolution + main stream + DWDR + IR intensity): 4.4W (12V DC); 5.2W (PoE)
Environment
Operating Temperature
–40°C to +60°C (–40°F to +140°F)
Operating Humidity
≤95%
Storage Temperature
–40°C to +60°C (–40°F to +140°F)
Protection
IP67
Structure
Casing
Metal
Product Dimensions
162.1 mm × Φ70.1 mm (6.38"" × Φ2.76"")
Net Weight
0.32 kg (0.71 lb)
Gross Weight
0.45 kg (0.99 lb)
Így is ismerheti: IPC HDW 1830 T 0280 B S 6, IPCHDW1830T0280BS6, IPC HDW1830T 0280B S6, IPC HDW1830T-0280B-S6, IPC-HDW1830T-0280B-S 6
