Camera

Image Sensor
1/2.8 2Megapixel progressive scan CMOS

Effective Pixels
1920(H)x1080(V)

RAM/ROM
1024MB/4096MB

Scanning System
Progressive

Electronic Shutter Speed
Auto/Manual, 1/3~1/100000s

Minimum Illumination
0.006Lux/F1.6 (Color, 1/3s, 30IRE)

0.05Lux/F1.6(Color, 1/30s, 30IRE)

0Lux/F1.6(IR on)

S/N Ratio
Less than 50dB

IR Distance
Distance up to 50m(164ft)

IR On/Off Control
Auto/Manual

IR LEDs
3

Lens

Lens Type
Motorized

Mount Type
Board-in

Focal Length
2.7~13.5mm motorized

Max. Aperture
F1.6

Angle of View
H: 107.17° ~ 31.82°, V: 56.47° ~ 17.62°

Optical Zoom
5x

Focus Control
Motorized

Close Focus Distance
0.3m(0.98ft)

DORI Distance
Lens
Detect
Observe
Recognize
Identify

W
44m(144ft)
18m(59ft)
9m(29ft)
4m(13ft)

T
153m(502ft)
61m(200ft)
31m(102ft)
15m(49ft)

Pan/Tilt/Rotation

Pan/Tilt/Rotation Range
Pan:0˚~355˚; Tilt:0˚~65˚; Rotation:0˚~355˚

Artificial Intelligence

People Counting
Line crossing people counting, Region people counting, Loitering filter

Perimeter Protection
Tripwire, Intrusion(Human&Vehicle classification)

General Intelligence

Event Trigger
Motion detection, Video tampering , Scene changing, Network disconnection , IP address conflict, Illegal Access, Storage anomaly

General Intelligence
N/A

Video

Compression
H. 265/H. 264/H. 264B/H. 264H/MJPEG(sub stream)

Smart Codec
Support H. 265+/H. 264+

Streaming Capability
3 Streams

Resolution
1080P(1920×1080)/ 1.3M(1280x960)/ 720P(1280x720)/ D1(704×576/704x480)/ VGA(640x480)

Frame Rate
Main Stream: 1080P(1~50/60fps)

Sub Stream: D1 (1 ~ 50/60fps)

Third Stream: 1080P(1~19/29fps)

Bit Rate Control
CBR/VBR

Bit Rate
H. 264: 24~ 10240Kbps

H. 265: 14~ 6144Kbps

Day/Night
Auto(ICR) / Color / B/W

BLC Mode
BLC / HLC / WDR(140dB)/ SSA

White Balance
Auto/Manual

Gain Control
Auto/Manual

Noise Reduction
3D DNR

Motion Detection
Off / On (4 Zone, Rectangle)

Region of Interest
Off / On (4 Zone)

Electronic Image Stabilization (EIS)
Support

Smart IR
Support

Defog
Support

Digital Zoom
16x

Flip
0°/90°/180°/270°

Mirror
Off / On

Privacy Masking
Off / On (4 Area, Rectangle)

Audio

Compression
G. 711a/ G. 711Mu/ AAC/ G. 726

Network

Ethernet
RJ-45 (100/1000Base-T)

Protocol
HTTP;HTTPs;TCP;ARP;RTSP;RTP;UDP;RTCP ;SMTP;

FTP;DHCP;DNS;DDNS;PPPOE;IPv4/v6;QoS; UPnP;

NTP;Bonjour;IEEE 802.1x;Multicast;ICMP;IGMP;S

NMP;TLS

Interoperability
ONVIF Profile S&G, API

Streaming Method
Unicast / Multicast

Max. User Access
10 Users/20 Users

Edge Storage
NAS

Local PC for instant recording

Micro SD card 128GB

Web Viewer
IE, Chrome, Firefox, Safari

Management Software
Smart PSS, DSS, DMSS

Smart Phone
IOS, Android

Certifications

Certifications
CE (EN 60950:2000)

UL:UL60950-1

FCC: FCC Part 15 Subpart B

Interface

Video Interface
1 Port(For adjustment only)

Audio Interface
1/1 channel In/Out

RS485
1 port

Alarm
1 channel In: 5mA 5VDC

1 channel Out: 1A 30VDC / 0.5A 50VAC

Electrical

Power Supply
DC12V, AC24V, PoE(802.3at)(Class 4)

Power Consumption
DC12V:5.8W 16.4W(IR on)

PoE:5.3W 14.7W(IR on)

Environmental

Operating Conditions
-30° C ~ +60° C (-22° F ~ +140° F) / Less than 95% RH

Storage Conditions
-30° C ~ +60° C (-22° F ~ +140° F) / Less than 95% RH

Ingress Protection
IP67

Vandal Resistance
IK10

Construction

Casing
Metal

Dimensions
Φ159.1mm*117.9mm

Net Weight
1.06Kg (2.34lb)

Gross Weight
1.28Kg (2.82lb)
