Dahua IPC-CD2C40M-ZS-2812
Dahua IPC-CD2C40M-ZS-2812
69 999 Ft
Ajánlataink Dahua IPC-CD2C40M-ZS-2812 termékre
Ajánlataink a termékre
Paraméterek, termékleírás - Dahua IPC-CD2C40M-ZS-2812
Galéria - Dahua IPC-CD2C40M-ZS-2812
Árdiagram
Áttekintést kaphat a termék árának alakulásáról.
Árfigyelő
Árfigyelő szolgáltatásunk értesíti, ha a termék a megjelölt összeg alá esik.
Aktuális legalacsonyabb ár: 69 999 Ft
További termékek a kategóriából
További Dahua termékek: Dahua IP kamera
Termékleírás
| Kialakítás | Dóm kamera |
| Energiaforrás | Hálózat és PoE |
| Felbontás | 4 MPx |
| Minimális fókusztávolság | 2.8 mm |
| Maximális fókusztávolság | 12 mm |
| IK védettség | IK10 |
| IP védettség | IP67 |
| Éjjellátó funkció | Van |
Hibát talált a leírásban vagy az adatlapon? Jelezze nekünk!
Camera
Image Sensor
1/3 4Megapixel progresive CMOS
Effective Pixels
2560(H)x1440(V)
RAM/ROM
256MB/16MB
Scanning System
Progressive
Electronic Shutter Speed
Auto/Manual, 1/3~1/100000s
Minimum Illumination
0.05Lux/F1.8( Color, 1/3s, 30IRE)
0.3Lux/F1.8( Color, 1/30s, 30IRE)
0Lux/F1.8(IR on)
S/N Ratio
More than 50dB
IR Distance
Distance up to 30m(98ft)
IR On/Off Control
Auto/ Manual
IR LEDs
2
Lens
Lens Type
Motorized
Mount Type
Board-in
Focal Length
2.8mm~12mm
Max. Aperture
F1.8
Angle of View
H:97°~31°, V:54°~17°
Focus Control
Fixed
Close Focus Distance
0.2m(0.66ft)
DORI Distance
Lens
Detect
Observe
Recognize
Identify
W
66m(216.5ft)
26.4m(86.6ft)
13.2m(43.3ft)
6.6m(21.7ft)
T
200m(656.2ft)
80m(262.5ft)
40m(131.2ft)
20m(65.6ft)
PTZ
Pan/Tilt Range
Pan:0° ~355° ;Tilt:0° ~75° ;Rotation:0° ~355°
Intelligence
Event Trigger
Motion detection, Video tampering , Network disconnection , Scene change, IP address conflict, Illegal Access, Storage anomaly
Video
Compression
H. 265/H. 264/H. 264B/MJPEG(Sub Stream)
Smart Codec
Support H. 265+/H. 264+
Streaming Capability
2 Streams
Resolution
4M(2560x1440)/3M(2304×1296)/1080P(1 920×1080)/720P(1280×720)/VGA(640×480) /D1(704×576/704×480)/CIF(352×288/352 240)
Frame Rate
Main Stream: 4M(1 ~ 20fps)
Sub Stream: D1(1 ~ 25/30fps)
Bit Rate Control
CBR/VBR
Bit Rate
H. 264: 32K~6144K
H. 265: 12K~ 6144K
Day/Night
Auto(ICR) / Color / B/W
BLC Mode
BLC / HLC / DWDR
White Balance
Auto/Natural/Street Lamp/Outdoor/Manual
Gain Control
Auto/Manual
Noise Reduction
3D DNR
Motion Detetion
Off / On (4 Zone, Rectangle)
Region of Interest
Off / On (4 Zone)
Electronic Image Stabilization (EIS)
N/A
Smart IR
Support
Digital Zoom
16x
Flip
0°/90°/180°/270°
Mirror
Off / On
Privacy Masking
Off / On (4 Area, Rectangle)
Audio
Compression
N/A
Network
Ethernet
RJ-45 (10/100Base-T)
Protocol
HTTP;HTTPS;TCP;ARP;RTSP;RTP;RTCP;UDP ;SMTP;
FTP;DHCP;DNS;DDNS;IPV4/V6;QoS;UPnP;
NTP;Bonjour;Multicast;ICMP;IGMP;TLS; SSH
Streaming Method
Unicast / Multicast
Max. User Access
10 Users/20 Users
Edge Storage
NAS(Network Attached Storage)
Local PC for instant recording
Micro SD Card 128GB
Web Viewer
IE, Chrome, Firefox, Safari
Management Software
Smart PSS, DSS, DMSS
Smart Phone
IOS, Android
Certifications
Certifications
CE: (EN 60950:2000)
FCC: FCC Part 15 Subpart B
Interface
Video Interface
N/A
Audio Interface
N/A
RS485
N/A
Alarm
N/A
Electrical
Power Supply
DC12V, PoE (802.3af)(Class 0)
Power Consumption
DC12V: 1.8W, 5.6W(IR On)
PoE: 2.1W, 6.5W(IR On)
Environmental
Operating Conditions
-30° C ~ +60° C (-22° F ~ +140° F) / Less than 95% RH
Strorage Conditions
-30° C ~ +60° C (-22° F ~ +140° F) / Less than 95% RH
Ingress Protection
IP67
Vandal Resistance
N/A
Construction
Casing
Plastic
Dimensions
Φ122mm × 98.1mm (4.8"" x3.86"")
Net Weight
0.381Kg (0.84lb)
Gross Weight
0.562Kg (1.24lb)
Így is ismerheti: IPC CD 2 C 40 M ZS 2812, IPCCD2C40MZS2812, IPC CD2C40M ZS 2812, IPC CD2C40M-ZS-2812, IPC-CD2C40M-ZS 2812
![]()
Image Sensor
1/3 4Megapixel progresive CMOS
Effective Pixels
2560(H)x1440(V)
RAM/ROM
256MB/16MB
Scanning System
Progressive
Electronic Shutter Speed
Auto/Manual, 1/3~1/100000s
Minimum Illumination
0.05Lux/F1.8( Color, 1/3s, 30IRE)
0.3Lux/F1.8( Color, 1/30s, 30IRE)
0Lux/F1.8(IR on)
S/N Ratio
More than 50dB
IR Distance
Distance up to 30m(98ft)
IR On/Off Control
Auto/ Manual
IR LEDs
2
Lens
Lens Type
Motorized
Mount Type
Board-in
Focal Length
2.8mm~12mm
Max. Aperture
F1.8
Angle of View
H:97°~31°, V:54°~17°
Focus Control
Fixed
Close Focus Distance
0.2m(0.66ft)
DORI Distance
Lens
Detect
Observe
Recognize
Identify
W
66m(216.5ft)
26.4m(86.6ft)
13.2m(43.3ft)
6.6m(21.7ft)
T
200m(656.2ft)
80m(262.5ft)
40m(131.2ft)
20m(65.6ft)
PTZ
Pan/Tilt Range
Pan:0° ~355° ;Tilt:0° ~75° ;Rotation:0° ~355°
Intelligence
Event Trigger
Motion detection, Video tampering , Network disconnection , Scene change, IP address conflict, Illegal Access, Storage anomaly
Video
Compression
H. 265/H. 264/H. 264B/MJPEG(Sub Stream)
Smart Codec
Support H. 265+/H. 264+
Streaming Capability
2 Streams
Resolution
4M(2560x1440)/3M(2304×1296)/1080P(1 920×1080)/720P(1280×720)/VGA(640×480) /D1(704×576/704×480)/CIF(352×288/352 240)
Frame Rate
Main Stream: 4M(1 ~ 20fps)
Sub Stream: D1(1 ~ 25/30fps)
Bit Rate Control
CBR/VBR
Bit Rate
H. 264: 32K~6144K
H. 265: 12K~ 6144K
Day/Night
Auto(ICR) / Color / B/W
BLC Mode
BLC / HLC / DWDR
White Balance
Auto/Natural/Street Lamp/Outdoor/Manual
Gain Control
Auto/Manual
Noise Reduction
3D DNR
Motion Detetion
Off / On (4 Zone, Rectangle)
Region of Interest
Off / On (4 Zone)
Electronic Image Stabilization (EIS)
N/A
Smart IR
Support
Digital Zoom
16x
Flip
0°/90°/180°/270°
Mirror
Off / On
Privacy Masking
Off / On (4 Area, Rectangle)
Audio
Compression
N/A
Network
Ethernet
RJ-45 (10/100Base-T)
Protocol
HTTP;HTTPS;TCP;ARP;RTSP;RTP;RTCP;UDP ;SMTP;
FTP;DHCP;DNS;DDNS;IPV4/V6;QoS;UPnP;
NTP;Bonjour;Multicast;ICMP;IGMP;TLS; SSH
Streaming Method
Unicast / Multicast
Max. User Access
10 Users/20 Users
Edge Storage
NAS(Network Attached Storage)
Local PC for instant recording
Micro SD Card 128GB
Web Viewer
IE, Chrome, Firefox, Safari
Management Software
Smart PSS, DSS, DMSS
Smart Phone
IOS, Android
Certifications
Certifications
CE: (EN 60950:2000)
FCC: FCC Part 15 Subpart B
Interface
Video Interface
N/A
Audio Interface
N/A
RS485
N/A
Alarm
N/A
Electrical
Power Supply
DC12V, PoE (802.3af)(Class 0)
Power Consumption
DC12V: 1.8W, 5.6W(IR On)
PoE: 2.1W, 6.5W(IR On)
Environmental
Operating Conditions
-30° C ~ +60° C (-22° F ~ +140° F) / Less than 95% RH
Strorage Conditions
-30° C ~ +60° C (-22° F ~ +140° F) / Less than 95% RH
Ingress Protection
IP67
Vandal Resistance
N/A
Construction
Casing
Plastic
Dimensions
Φ122mm × 98.1mm (4.8"" x3.86"")
Net Weight
0.381Kg (0.84lb)
Gross Weight
0.562Kg (1.24lb)
Így is ismerheti: IPC CD 2 C 40 M ZS 2812, IPCCD2C40MZS2812, IPC CD2C40M ZS 2812, IPC CD2C40M-ZS-2812, IPC-CD2C40M-ZS 2812
